Use Cases in Action

LED Driver Array ASIC with LVDS Interface for High-speed Digital Printer

use-case-in-action (2)
  • 198 LED driver array, individual drivers are controlled by a precision 8b segmented DAC with current steps of 6 µA
  • Diagnosis circuitry is built-in that detects a faulty condition of the current source, which is also reused for ATE production testing
  • Wafer test on TeradyneJ750EX
    • All modules tested
  • 198 LED driver array, individual drivers are controlled by a precision 8b segmented DAC with current steps of 6 µA
  • Diagnosis circuitry is built-in that detects a faulty condition of the current source, which is also reused for ATE production testing
  • Wafer test on TeradyneJ750EX
    • All modules tested
use-case-in-action (2)

High Performance ASIC for Water Meter

use-case-in-action (3)
  • Full turnkey solution from design to supply chain management for higher precision flow speed and temperature metering chipset in TSMC 180 nm
  • Featured with low-noise TIA design for detecting pA(rms) level acoustic signals and 60dB dynamic range & Temperature sensor compatible with PT100 and PT500 achieving 0.1°C accuracy
  • Multi-chip system-in-package (SIP): ASIC + off-the shelve MCU
  • Wafer Sorting of ASIC on D10
    • All modules tested
  • Final test developed in-house & transferred to V93000 quad-site solution at HuaTian
    • Mainly contact, leakage, and interconnection tests
  • Full turnkey solution from design to supply chain management for higher precision flow speed and temperature metering chipset in TSMC 180 nm
  • Featured with low-noise TIA design for detecting pA(rms) level acoustic signals and 60dB dynamic range & Temperature sensor compatible with PT100 and PT500 achieving 0.1°C accuracy
  • Multi-chip system-in-package (SIP): ASIC + off-the shelve MCU
  • Wafer Sorting of ASIC on D10
    • All modules tested
  • Final test developed in-house & transferred to V93000 quad-site solution at HuaTian
    • Mainly contact, leakage, and interconnection tests
use-case-in-action (3)

NFC ASIC 13.56 MHz with no EM Filter

use-case-in-action (4)
  • Novel PA and receiver architecture that requires no external EM filter or the use of a high voltage silicon technology
  • Featured with single power supply operation with separate I/O supply voltage of 1.8V and 3.3V featuring power management
  • TSMC 180nm / ASE
  • Production test developed on NI-STS production tester (Final Test)
  • Ramp up of first 500,000 pcs in-house
  • Transferred to V93K & OSAT in ASIA for high volume production
  • Novel PA and receiver architecture that requires no external EM filter or the use of a high voltage silicon technology
  • Featured with single power supply operation with separate I/O supply voltage of 1.8V and 3.3V featuring power management
  • TSMC 180nm / ASE
  • Production test developed on NI-STS production tester (Final Test)
  • Ramp up of first 500,000 pcs in-house
  • Transferred to V93K & OSAT in ASIA for high volume production
use-case-in-action (4)

High Precision GPS Receiver for ADAS (Quabanatu)

use-case-in-action (1)
  • GPS Receiver with mm accuracy for autonomous driving
  • Fully integrated transceiver with LNA, PLL, programmable 7th order filter
  • AEC-Q100 certified
  • Production test developed on NI-STS production tester (Final Test)
  • Ramp up of first 100,000 pcs in-house
  • Whole test range from digital, analog, and RF in the package
  • TSMC 65nm, automotive compliant IAT16949 supply chain
  • GPS Receiver with mm accuracy for autonomous driving
  • Fully integrated transceiver with LNA, PLL, programmable 7th order filter
  • AEC-Q100 certified
  • Production test developed on NI-STS production tester (Final Test)
  • Ramp up of first 100,000 pcs in-house
  • Whole test range from digital, analog, and RF in the package
  • TSMC 65nm, automotive compliant IAT16949 supply chain
use-case-in-action (1)
