Advancing commercial air travel, missile technology, and unmanned aerial vehicles are driving growth across the airborne radar market. Aerospace and defense OEMs are turning to suppliers to reduce size, weight, and time-to-market while enhancing reliability. The Cyient X-Band Transmit and Receive Module (TRM) offers an innovative solution to OEMs seeking a lightweight, ITAR-free TR Module for Active Electronically Scanned Array (AESA) radar systems.

The Cyient X-Band TR Module’s unique architecture and small form factor yield a 20% reduction in weight when compared to conventional X-Band TR Modules. The Cyient TRM is designed using hybrid PCB technology and non-ITAR components, enabling OEMs to exercise offset obligations with improved efficiencies. Cyient's X-Band TR Module uses prescreened products and a COTS design approach that automates the assembly process and significantly reduces manufacturing and qualification costs.

Cyient X-Band TR Module Benefits

Radar Image 2 - shutterstock_155402870 - 690x470px

Reduced Module Size and Weight

Reduce product weight by more than 20% with the Cyient X-Band TR Module, designed using hybrid PCB technology without the need for traditional connectors.

Simplified Qualification Process - shutterstock_1381707254 - 690x470px

Simplified Qualification Process

Exercise offset obligations without ITAR restrictions with the Cyient X-Band TR Module that uses pre-screened products requiring moderate qualification.

Streamline RADAR System Production - shutterstock_448317853 - 690x470px

Streamlined RADAR System Production

Increase efficiency and delivery with the Cyient X-Band TR Module that uses off-the-shelf SMD components to enable production in standard reflow SMT PCB assembly line.

shutterstock_1445241848 - 690x470px

Increased System Reliability

Increase efficiency and delivery with the Cyient X-Band TR Module that uses off-the-shelf SMD components to enable production in standard reflow SMT PCB assembly line.

Reduced Module Size and Weight

Simplified Qualification Process

Streamlined RADAR System Production

Increased System Reliability

The Cyient X-Band TR Module Applications

  • Airborne Radar
  • Air Traffic Control Radar
  • Ground-Based Radar
  • Vehicle-Mounted Radar
  • Naval/Marine Radar
  • Border Surveillance Radar
Transmit And Receive Module Radar Systems

Discover how you can streamline production and qualification processes for TR Modules in AESA RADAR systems.

TR Modules for AESA Radar Solutions

Given the manufacturing complexities and export control regulations, standard TR Modules available today are extremely expensive. TR Modules are also the building blocks for AESA radars and account for over 33% of normalized system production costs. Addressing these challenges starts at the component level, where the design, development, and qualification processes play a crucial role in system optimization. Conventional designs use chip & wire bond assembly that results in poor yield and high cost of manufacturing. Standard TR Modules also use connectors that increase overall product weight.



CYIENT X BAND TRM_1 (1)



With a 20% reduction in weight, the Cyient X-Band TR Module delivers:

  • Power 5W class (GaN)
  • 5 dB noise figure
  • 6-bit phase control
  • 5-bit amplitude control
  • Digital control
  • Connector-less design
  • Weight: 20 grams
